Professional FM200 Fire System Automatic Refilling Equipment for Industrial Safety

Détails du produit

Lieu d'origine: Canton, Chine

Nom de marque: XINGJIN

Certification: CCC,CAC,ROHS

Numéro de modèle: Xj-qeo-006

Conditions de paiement et d'expédition

Quantité de commande min: 1 Définir le système

Prix: Pricing based on quantity

Détails d'emballage: Boîte en bois ou boîte extérieure en contreplaqué avec sac à bulles ou papier

Délai de livraison: Selon la quantité de produit

Conditions de paiement: T/T, LC

Capacité d'approvisionnement: 3000set/mois

Obtenez le meilleur prix
Détails du produit
Mettre en évidence:
Agent d'extinction d'incendie applicable:
Perfluorohexanone, azote
Pression de remplissage maximale:
6.0 Mpa
Plage de décompression de l'azote:
0 ~ 10 MPa réglable (couramment utilisé: 4,2 MPa, 5,6 MPa)
Pression de sortie de médicament:
0 ~ 3,6 MPa
degré de vide:
≤ -0,09 MPa
Alarme de pression de remplissage:
0 ~ 10 MPa (réglable, le voyant d'alarme s'allume lors de l'atteinte de la valeur défini
Densité de remplissage:
≤ 1420 kg / m³
Exactitude de remplissage:
± 0,5%
Température ambiante:
0 ~ 50 ℃
Exigences d'alimentation:
AC 220V,50 Hz
Taille de l'équipement:
720 × 800 × 1280 mm (à l'exclusion du coureur)
Fil de connexion externe:
Sujets pour réactif d'entrée et de sortie et interface d'azote: M22 × 1,5
Agent d'extinction d'incendie applicable:
Perfluorohexanone, azote
Pression de remplissage maximale:
6.0 Mpa
Plage de décompression de l'azote:
0 ~ 10 MPa réglable (couramment utilisé: 4,2 MPa, 5,6 MPa)
Pression de sortie de médicament:
0 ~ 3,6 MPa
degré de vide:
≤ -0,09 MPa
Alarme de pression de remplissage:
0 ~ 10 MPa (réglable, le voyant d'alarme s'allume lors de l'atteinte de la valeur défini
Densité de remplissage:
≤ 1420 kg / m³
Exactitude de remplissage:
± 0,5%
Température ambiante:
0 ~ 50 ℃
Exigences d'alimentation:
AC 220V,50 Hz
Taille de l'équipement:
720 × 800 × 1280 mm (à l'exclusion du coureur)
Fil de connexion externe:
Sujets pour réactif d'entrée et de sortie et interface d'azote: M22 × 1,5
Description du produit

Heptafluoropropane fire extinguishing agent filling equipment


Product Overview:

Heptafluoropropane fire extinguishing agent filling equipment is a professional device that integrates high efficiency, safety and precision, and is suitable for
  Heptafluoropropane fire extinguishing agent filling. The equipment is equipped with nitrogen pressure reduction, filling pressure alarm, vacuum pumping system and weight reporting
  The alarm node reserves interfaces to support multiple gas cylinder specifications, ensuring the airtightness and accuracy during the fire extinguishing agent filling process
Professional FM200 Fire System Automatic Refilling Equipment for Industrial Safety 0

Technical Parameter:

Project Parameter
Suitable Extinguishing Media FM200(HFC-227ea),Nitrogen
Maximum Filling Pressure 5.6 MPa
Nitrogen Pressure Reduction Range 0~ 10 MPa adjustable (commonly used: 2.5 MPa, 4.2 MPa, 5.6 MPa)
Drug Output Pressure 0~3.6 MPa
Vacuum Degree ≤ -0.09 MPa
Filling Pressure Alarm 0~ 10 MPa (Adjustable to set value, alarm warning light on)
Filling Density ≤ 950 kg/m³
Filling Accuracy ±0.5%
Ambient Temperature 0~50℃
Power Requirements AC 220V ,50Hz
Equipment Size 720×800×1280 mm (Excluding the wheel)
External Connection Thread Drug inlet and outlet threads and nitrogen interface: M22 × 1.5
Other Reserved weight alarm indicator interface (requires external intelligent electronic weighing device)

Professional FM200 Fire System Automatic Refilling Equipment for Industrial Safety 1

 Equipment valve body function:

F1 pressure reducing valve Control the pressure of nitrogen entering the system to ensure stable and safe filling process.
F2 pressure relief valve

Release excess pressure in emergency situations to protect equipment and gas

cylinders from high pressure damage.

F3 Pharmaceutical Storage Valve Control the pipeline for the flow of fire extinguishing agent from the storage tank to the filling cylinder.







F4 nitrogen storage valve Control the entry of nitrogen from the storage tank into the equipment pipeline to provide pressure for the filling of fire extinguishing agents.
F5 gas cylinder valve

Used to connect fire extinguishing agent cylinders and control the opening or closing

of cylinder fluid pipelines.

F6 vacuum valve Used to open or close the air inside the extracted gas cylinder, reduce the pressure inside the cylinder, and ensure the purity of the fire extinguishing agent filling.
